EFFICIENT COOLING SOLUTIONS FOR LARGE COMMERCIAL SPACES.
PRIME GUARD HYPER GRAPFINS™
5X Protection against corrosion.
INVERTER COMPRESSOR
More energy savings
LONG DISTANCE AIRFLOW
More even and comfortable cooling experience
Full specifications
-
Standard Conditions
-
Power Supply
230V,1Ph,60Hz
-
Capacity
52000
-
Input (W)
5440
-
Current (A)
24.1
-
EER
9.56
-
–
-
Rated Power Input
6290
-
Rated current
28
-
-
Physical Data (Indoor Unit):
-
Indoor air flow (Hi/Mi/Lo)
2,200/2,200/1,750
-
Indoor Noise Level (Hi/Lo)dB(A):
53.0/0/48.5
-
Dimension (WxDxH)(mm):
600x455x1,934
-
Packing (WxDxH)(mm):
2,080x755x585
-
Net Gross Weight
62/82.2
-
-
Physical Data (Outdoor Unit):
-
Outdoor air flow
4800
-
Outdoor Noise Level dB(A):
63.5
-
Dimension (WxDxH)(mm):
946x410x810
-
Packing (WxDxH)(mm):
1,090x500x885
-
Net Gross Weight
63.9/68.9
-
-
Product Specifications:
-
Refrigerant Type
R32/2.65
-
Design pressure (145psi=1MPa )(L/H)
4.3/1.7
-
Liquid side/ Gas side
9.52mm(3/8in)/15.9mm(5/8in)
-
Max. refrigerant pipe length
50
-
Connection wiring
1.0×4
-
Plug Type
No Plug
-
Thermostat type
Remote-Controlled
-
Operation temperature
17 ~ 30
-
Application area (Cooling Standard)
69～102
-
Warranty
Parts and Service: 1 Year | Indoor & Outdoor PCBs: 3 Year | Indoor & Outdoor Fan Motors: 3 Year | Compressor: 10 Year
-
